The TSOP6236TR is a miniaturized IR receiver module designed for IR remote control systems. It is a surface mount device (SMD) that integrates a photodiode, preamplifier, and IR filter into a single compact package. This module is part of the TSOP62 series and is optimized for receiving infrared signals modulated at a specific carrier frequency.

Applications

• Remote control systems for TVs, DVD players, audio equipment, and other consumer electronics
• Touch-free sensors
• Light curtain applications
• Proximity sensors
• IR data transmission

Features

• SMD Version
• Improved immunity against disturbances
• Internal filter for PCM frequency
• Low supply current
• Photo detector and preamplifier in one package
• TTL and CMOS compatibility
• Output active low
• Carrier frequency: 36 kHz
• Supply voltage: 2.7 V to 5.5 V
• RoHS compliant

Benefits

• Reliable performance in noisy environments due to improved immunity against disturbances.
• Low power consumption, making it suitable for battery-powered applications.
• Easy to integrate into existing designs due to its compact size and standard pinout.
• Provides a stable and clean output signal, ensuring accurate data transmission.
• Reduced space requirements due to SMD package

Additional Details

The TSOP6236TR operates at a carrier frequency of 36 kHz. The internal filter effectively blocks out ambient light and other sources of infrared radiation that could interfere with the desired signal. The module's output is an active-low signal. The power supply range is typically from 2.7 V to 5.5 V. The device is suitable for surface mount assembly.
