VS-12CWQ10FNTRPBF Real Image VS-12CWQ10FNTRPBF label picture
Same model may have multiple batches, images only for reference.
VS-12CWQ10FNTRPBF Real Image VS-12CWQ10FNTRPBF label picture
VS-12CWQ10FNTRPBF Real Image VS-12CWQ10FNTRPBF label picture
Same model may have multiple batches, images only for reference.

VS-12CWQ10FNTRPBF

Part No VS-12CWQ10FNTRPBF
Manufacturer Vishay
Catalog Diodes, Rectifiers - Arrays
Description DIODE ARRAY SCHOTTKY 100V DPAK / Rectifier Diode Schottky 100V 12A 3-Pin(2+Tab) DPAK T/R
Datasheet
VS-12CWQ10FNTRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Obsolete(EOL)
Diode Configuration 1 Pair Common Cathode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 100V
Current - Average Rectified (Io) (per Diode) 6A
Voltage - Forward (Vf) (Max) @ If 800mV @ 6A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 1mA @ 100V
Operating Temperature - Junction -55°C to 150°C
Mounting SMD (SMT)
Case / Package D-PAK (TO-252AA)
Win Source Part Number 005234-VS-12CWQ10FNTRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Quantity per package 2k pcs
Family Name VS-12CWQ10FN
Introduction Date November 30, 2010
ECCN EAR99
Country of Origin China
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian VS-12CWQ10FNTRPBF CAD Model

Description

The Win Source Part Number for this product is 005234. This product is a Schottky diode with a voltage rating of 100V and a current rating of 6A.

  • Win Source Part Number: 005234
  • Voltage Rating: 100V
  • Current Rating: 6A
  • Status: obsolete (EOL)
