BT300S-600R,118 WeEn Semiconductors BT300S-600R,118 real image
Same model may have multiple batches, images only for reference.
BT300S-600R,118 WeEn Semiconductors BT300S-600R,118 real image
BT300S-600R,118 WeEn Semiconductors BT300S-600R,118 real image
Same model may have multiple batches, images only for reference.

BT300S-600R,118

Part No BT300S-600R,118
Manufacturer WeEn Semiconductors
Catalog SCRs - Single
Description THYRISTOR 8A 600V DPAK
Datasheet
BT300S-600R,118 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer WeEn Semiconductors
Packaging Reel - TR
Status Active
Voltage - Off State 600V
Voltage - Gate Trigger (Vgt) (Max) 1.5V
Current - Gate Trigger (Igt) (Max) 15mA
Voltage - On State (Vtm) (Max) 1.6V
Current - On State (It (AV)) (Max) 5A
Current - On State (It (RMS)) (Max) 8A
Current - Hold (Ih) (Max) 20mA
Current - Off State (Max) 500μA
Current - Non Rep. Surge 50, 60Hz (Itsm) 65A, 71A
SCR Type Standard Recovery
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package DPAK
Win Source Part Number 1024673-BT300S-600R,118
Popularity Medium
Supply and Demand Status Sufficient
Quantity per package 2,500
Ultra Librarian 3D Model Ultra Librarian BT300S-600R,118 CAD Model

Description

The BT300S-600R,118 is a standard recovery SCR with a maximum voltage - off state of 600V and a current - on state (It (AV)) (Max) of 5A.

  • Type: Standard Recovery SCR
  • Voltage - Off State: 600V
  • Current - On State (It (AV)) (Max): 5A
  • Voltage - On State (Vtm) (Max): 1.6V
  • Current - On State (It (RMS)) (Max): 8A
  • Current - Hold (Ih) (Max): 20mA
  • Current - Non Rep. Surge 50, 60Hz (Itsm): 65A, 71A
  • Package/Case: DPAK
  • Mounting Type: SMD (SMT)
  • Suitable For: Discrete Semiconductor Products
