BTA420X-800BT,127 WeEn Semiconductors BTA420X-800BT,127 label picture BTA420X-800BT,127 real image
Same model may have multiple batches, images only for reference.
BTA420X-800BT,127 WeEn Semiconductors BTA420X-800BT,127 label picture BTA420X-800BT,127 real image
BTA420X-800BT,127 WeEn Semiconductors BTA420X-800BT,127 label picture BTA420X-800BT,127 real image
Same model may have multiple batches, images only for reference.

BTA420X-800BT,127

Part No BTA420X-800BT,127
Manufacturer WeEn Semiconductors
Catalog Triacs
Description TRIAC 800V 20A TO220F / TRIAC 800V 20A(RMS) 220A 3-Pin(3+Tab) TO-220F Rail
Datasheet
BTA420X-800BT,127 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer WeEn Semiconductors
Packaging Tube
Triac Type Standard
Voltage - Off State 800V
Current - On State (It (RMS)) (Maximum) 20A
Voltage - Gate Trigger (Vgt) (Maximum) 1.5V
Current - Non Rep. Surge 50, 60Hz (Itsm) 200A, 220A
Current - Gate Trigger (Igt) (Maximum) 50mA
Current - Hold (Ih) (Maximum) 60mA
Configuration Single
Operating Temperature Range 150°C (TJ)
Mounting Style Through Hole
Package TO-220-3 Full Pack, Isolated Tab
Manufacturer Package TO-220F
Win Source Part Number 770554-BTA420X-800BT,127
Popularity Medium
Supply and Demand Status Limited
Quantity per package 1k pcs
Family Name BTA420X-800BT
Introduction Date August 05, 2015
ECCN EAR99
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian BTA420X-800BT,127 CAD Model

Description

The WeEn Semiconductors BTA420X-800BT,127 is a high-quality triac designed for use in a variety of electronic applications.

  • Voltage Off State: 800V
  • Non-Repetitive Surge Current: 220A
  • Current On State: 20A
  • Voltage Gate Trigger: 1.5V
  • Configuration: Single
  • Package: TO-220-3 Full Pack, Isolated Tab
