74455233 Wurth Electronics Inc
Same model may have multiple batches, images only for reference.

74455233

Part No 74455233
Manufacturer Wurth Electronics Inc
Catalog Fixed Inductors
Description 330UH INDUCTOR 20%
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes - Fixed Inductors
Mfr Wurth Electronics Inc
Series WE-PD4
Package Tape & Reel
Product Status Active
Type Wirewound
Inductance 330 µH
Tolerance ±20%
Current Rating (Amps) 160 mA
Current - Saturation (Isat) 180mA
Shielding Unshielded
DC Resistance (DCR) 5Ohm Max
Frequency - Self Resonant 4MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting Type Surface Mount
Package / Case Nonstandard
Size / Dimension 0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max) 0.115" (2.92mm)
Standard Package 500 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 547317-74455233
Ultra Librarian 3D Model Ultra Librarian 74455233 CAD Model

Description

The WE-PD4 series from Wurth Electronics Inc offers compact and reliable wirewound inductors for a wide range of electronic applications.

  • Size: 0.260" L x 0.175" W (6.60mm x 4.45mm)
  • Height: 0.115" (2.92mm) max
  • Inductance: 330 µH
  • Tolerance: ±20%
  • Shielding: Unshielded
  • Current Rating: 160 mA max
  • DC Resistance (DCR): 5 Ohm max
  • Operating Temperature Range: -40°C to 125°C
  • Package: Nonstandard
  • Packaging: Tape and reel
