The NCE2301B is a P-Channel enhancement mode power MOSFET manufactured by Wuxi NCE Power Semiconductor Co., Ltd. It is designed for load switching and power management applications, particularly in portable devices and battery-powered systems. This MOSFET utilizes advanced trench technology to achieve low on-resistance and efficient switching performance.

Applications

• Load Switching
• Power Management in Portable Devices
• Battery Protection Circuits
• DC-DC Converters
• Linear Regulators

Features

• Low RDS(on)
• Fast Switching Speed
• Low Gate Charge
• Small Footprint
• RoHS Compliant

Benefits

• Increased Power Efficiency
• Reduced Switching Losses
• Improved Thermal Performance
• Simplified Circuit Design
• Enhanced System Reliability

Detailed Specs

The NCE2301B typically features a drain-source voltage (VDS) of -20V and a gate-source voltage (VGS) of ±8V. The continuous drain current (ID) is typically around -2.5A, although this value can vary based on the specific package and operating conditions. The RDS(on) is low, typically in the tens of milliohms range, which minimizes conduction losses. The device is commonly available in a SOT-23 or similar small surface-mount package, making it suitable for space-constrained applications. Its fast switching speed contributes to reduced switching losses in high-frequency power conversion circuits. The low gate charge simplifies the gate drive requirements. This P-Channel MOSFET is designed for efficient and reliable operation in a range of low-voltage switching applications, especially in portable electronic devices where power efficiency and small size are critical.
