The SW10N65K is a high-voltage N-channel MOSFET from Xian Semipower Electronic Technology Co., Ltd. This MOSFET is designed for high-efficiency power switching applications. It is built using advanced trench technology to minimize on-state resistance and gate charge, offering superior performance in demanding power electronic circuits.

Applications

• Switch Mode Power Supplies (SMPS)
• Power Factor Correction (PFC) circuits
• Uninterruptible Power Supplies (UPS)
• DC-DC converters
• Motor control circuits

Features

• High voltage capability: 650V
• Low on-resistance (RDS(on)) to minimize conduction losses
• Fast switching speed
• Low gate charge (Qg) for efficient switching
• Avalanche rated
• RoHS compliant
• Advanced trench technology

Benefits

• Improved efficiency in power conversion systems due to low RDS(on) and fast switching.
• Reduced power dissipation leading to lower operating temperatures and improved reliability.
• Simplified thermal management due to efficient operation.
• Enhanced system reliability due to avalanche ruggedness.
• Compliance with environmental regulations (RoHS).
• Higher power density due to smaller package size and efficient heat dissipation.

Additional Details

The SW10N65K typically comes in a TO-252 or TO-220 package. It is characterized by its high breakdown voltage and low on-resistance, making it suitable for applications where power efficiency and reliability are critical. The device's fast switching speed also minimizes switching losses, contributing to overall system efficiency. The gate threshold voltage is designed for easy driving, allowing for simple integration into existing circuits. The maximum drain current is 10A. The device is designed to operate over a wide temperature range, ensuring reliable performance in various operating environments.
