Products specifications

Category Power Supplies - Board Mount - DC DC Converters
Mfr XP Power
Series XP EMCO - C (1W)
Package Box
Product Status Active
Type High Voltage - Non-Isolated Module
Number of Outputs 1
Voltage - Input (Min) 11.5V
Voltage - Input (Max) 16V
Voltage - Output 1 2500V
Current - Output (Max) 400µA
Power (Watts) 1 W
Applications ITE (Commercial)
Features SCP
Temperature Range - Operating -10°C ~ 60°C
Mounting Type Through Hole
Package / Case 5-DIP Module
Size / Dimension 1.75" L x 1.11" W x 0.50" H (44.5mm x 28.2mm x 12.7mm)
Standard Number 62368-1
Standard Package 1 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.40.9580
Win Source Part Number 575706-C25
Ultra Librarian 3D Model Ultra Librarian C25 CAD Model

Description

The XP EMCO - C (1W) series is a high voltage non-isolated module designed by XP Power.

  • Power rating: 1W
  • Features: SCP (Short Circuit Protection)
  • Compact size: 1.75" L x 1.11" W x 0.50" H (44.5mm x 28.2mm x 12.7mm)
  • Voltage input: 11.5V to 16V
  • Voltage output: 2500V
  • Mounting: through hole
  • Package: 5-DIP module package.
  • Operating temperature: -10°C to 60°C.
  • Status: active product from XP Power
  • Applications: ITE (Commercial) applications.
