RC0805FR-0710KL Yageo RC0805FR-0710KL Real Image RC0805FR-0710KL Real Image1 RC0805FR-0710KL Real Image2
Same model may have multiple batches, images only for reference.
RC0805FR-0710KL Yageo RC0805FR-0710KL Real Image RC0805FR-0710KL Real Image1 RC0805FR-0710KL Real Image2
RC0805FR-0710KL Yageo RC0805FR-0710KL Real Image RC0805FR-0710KL Real Image1 RC0805FR-0710KL Real Image2
Same model may have multiple batches, images only for reference.

RC0805FR-0710KL

Part No RC0805FR-0710KL
Manufacturer Yageo
Catalog Chip Resistor - Surface Mount
Description RES SMD 10K OHM 1% 1/8W 0805
Datasheet
RC0805FR-0710KL Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Resistors
Manufacturer Yageo
Packaging Reel - TR
Status Active
Resistance (Ohms) 10k
Tolerance ±1%
Power (Watts) 0.125W, 1/8W
Composition Thick Film
Features Moisture Resistant
Temperature Coefficient ±100ppm/°C
Temperature Range - Operating -55°C to 155°C
Case / Package 0805
Height - Seated (Max) 0.024" (0.60mm)
Number of Terminations 2
Win Source Part Number 097590-RC0805FR-0710KL
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Industrial
Ultra Librarian 3D Model Ultra Librarian RC0805FR-0710KL CAD Model

Description

Yageo is the manufacturer of this electronic component with the Win Source Part Number 097590-RC0805FR-0710KL.

  • Supply and Demand Status: Balanced
  • Moisture-Resistant: Yes
  • Height: 0.024" (0.60mm) when seated
  • Tolerance: ±1%
  • Temperature Coefficient: ±100ppm/°C
  • Composition: Thick film
  • Power: 0.125W, 1/8W
  • Resistance: 10k Ohms
  • Application: Industrial
