Same model may have multiple batches, images only for reference.
929665-09-36-I Real Image
Same model may have multiple batches, images only for reference.

929665-09-36-I

Part No 929665-09-36-I
Manufacturer 3M
Catalog Circular Connectors - Housings
Description CONN HEADER VERT 72POS 2.54MM  /  Connector Header Through Hole 72 position 0.100" (2.54mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr 3M
Series 929
Package Bulk
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Number of Positions 72
Number of Rows 2
Row Spacing - Mating 0.100" (2.54mm)
Number of Positions Loaded All
Style Board to Board
Shrouding Unshrouded
Mounting Type Through Hole
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.235" (5.97mm)
Contact Length - Post 0.145" (3.68mm)
Overall Contact Length 0.480" (12.19mm)
Insulation Height 0.100" (2.54mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 10.0µin (0.25µm)
Contact Finish - Post Gold
Contact Material Copper Alloy
Insulation Material Polybutylene Terephthalate (PBT), Polyester, Glass Filled
Temperature Range - Operating -40°C ~ 105°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 2.5A
Contact Finish Thickness - Post 10.0µin (0.25µm)
Base Product Number 929665
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Other Names 7000058877,929665-09,54007808923,5400780892,80-6200-2526-4,9296650936I,80620025264,929665-09-36,3M156313-72,929665-09-36-ND
Standard Package 100
Win Source Part Number 980187-929665-09-36-I
Ultra Librarian 3D Model Ultra Librarian 929665-09-36-I CAD Model

Description

The 3M 929665-09-36-I is a 72-position male pin header connector that is ideal for board-to-board applications.

  • Contact Material: Copper Alloy
  • Contact Finish: Gold
  • Mating Contact Finish: Gold
  • Current Rating: 2.5A
  • Temperature Range: -40°C to 105°C
  • REACH: Unaffected
  • ECCN: EAR99
