The AMC7135 is a constant current LED driver manufactured by ADDtek Corp. It is designed to provide a regulated current to one or more LEDs, ensuring consistent brightness and preventing damage from overcurrent. This driver is often used in various lighting applications where stable and efficient LED operation is crucial.

Applications

• LED flashlights
• LED bicycle lights
• LED decorative lighting
• LED backlighting
• Portable LED lighting devices

Features

• Constant current output
• Wide input voltage range
• High efficiency
• Low dropout voltage
• Thermal protection

Benefits

• Consistent LED brightness regardless of battery voltage
• Longer LED lifespan due to regulated current
• Efficient power utilization
• Overheating protection to prevent damage
• Simple and compact design for easy integration

Technical Specifications

The AMC7135 typically supports an input voltage range of 2.7V to 6V and can deliver a constant output current of up to 350mA. It is available in various packages, such as SOT-89. The dropout voltage is typically low, allowing the LED to be driven even when the battery voltage is close to the LED's forward voltage. The thermal protection feature prevents the device from overheating by reducing the output current when the temperature exceeds a certain threshold.
