ACS71240LLCBTR-030B3 Real Image ACS71240LLCBTR-030B3 Real Image
Same model may have multiple batches, images only for reference.
ACS71240LLCBTR-030B3 Real Image ACS71240LLCBTR-030B3 Real Image
ACS71240LLCBTR-030B3 Real Image ACS71240LLCBTR-030B3 Real Image
Same model may have multiple batches, images only for reference.

ACS71240LLCBTR-030B3

Part No ACS71240LLCBTR-030B3
Manufacturer Allegro MicroSystems, LLC
Catalog Current Transducers
Description SENSOR CURRENT HALL 30A 8SOIC  /  Current Sensor 30A 1 Channel Hall Effect, Open Loop Bidirectional 8-SOIC (0.154", 3.90mm Width)
Datasheet
ACS71240LLCBTR-030B3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers>Current Sensors
Mfr Allegro MicroSystems
Series Automotive, AEC-Q100
Package Tape & Reel
For Measuring AC/DC
Sensor Type Hall Effect, Open Loop
Current - Sensing 30A
Number of Channels 1
Output Voltage
Sensitivity 44mV/A
Frequency 120kHz
Linearity ±1%
Accuracy ±6%
Voltage - Supply 3V ~ 3.6V
Response Time 4µs
Current - Supply (Max) 12mA
Temperature Range - Operating -40°C ~ 150°C (TA)
Polarization Bidirectional
Mounting SMD (SMT)
Package / Case 8-SOIC (0.154", 3.90mm Width)
Base Product Number ACS712
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Names 620-2052-2,620-2052-1,620-2052-6
Standard Package 3,000
Win Source Part Number 970686-ACS71240LLCBTR-030B3
Ultra Librarian 3D Model Ultra Librarian ACS71240LLCBTR-030B3 CAD Model

Description

The ACS71240LLCBTR-030B3 is a bidirectional current sensor that is used for measuring AC/DC current.

  • Type: Hall Effect, Open-Loop
  • Sensitivity: 44mV/A
  • Max Current: 30A
  • Output: Voltage
  • Linearity: ±1%
  • Accuracy: ±6%
  • Response Time: 4μs
  • Operating Temperature Range: -40°C to 150°C
  • Package: 8-SOIC
  • Voltage Supply: 3V to 3.6V
  • Application: Automotive
  • Standard: AEC-Q100
  • Packaging: Tape and Reel
  • Standard Package: 3,000
