ACS720KLATR-65AB-T Real Image ACS720KLATR-65AB-T Real Image
Same model may have multiple batches, images only for reference.
ACS720KLATR-65AB-T Real Image ACS720KLATR-65AB-T Real Image
ACS720KLATR-65AB-T Real Image ACS720KLATR-65AB-T Real Image
Same model may have multiple batches, images only for reference.

ACS720KLATR-65AB-T

Part No ACS720KLATR-65AB-T
Manufacturer Allegro MicroSystems, LLC
Catalog Current Transducers
Description CURRENT SENSOR  /  Current Sensor 65A 1 Channel Hall Effect, Open Loop Bidirectional 16-SOIC (0.295", 7.50mm Width)
Datasheet
ACS720KLATR-65AB-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers>Current Sensors
Mfr Allegro MicroSystems
Series ACS720
Package Tape & Reel
For Measuring AC/DC
Sensor Type Hall Effect, Open Loop
Current - Sensing 65A
Number of Channels 1
Output Ratiometric, Current
Sensitivity 20.5mV/A
Frequency 120kHz
Linearity ±0.75%
Accuracy ±1.6%
Voltage - Supply 4.5V ~ 5.5V
Response Time 4µs (Typ)
Current - Supply (Max) 16mA
Temperature Range - Operating -40°C ~ 125°C
Polarization Bidirectional
Mounting SMD (SMT)
Package / Case 16-SOIC (0.295", 7.50mm Width)
Supplier Device Package 16-SOIC
Base Product Number ACS720
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Names 620-1877-6,620-1877-1,620-1877-2
Standard Package 1,000
Win Source Part Number 971500-ACS720KLATR-65AB-T
Ultra Librarian 3D Model Ultra Librarian ACS720KLATR-65AB-T CAD Model

Description

The ACS720 current sensor is a Hall Effect, open-loop bidirectional sensor with a ratiometric output and a sensitivity of 20.5mV/A.

  • Type: Hall Effect, Open-Loop, Bidirectional
  • Output: Ratiometric
  • Sensitivity: 20.5mV/A
  • Current Measurement: AC/DC up to 65A
  • Accuracy: ±1.6%
  • Linearity: ±0.75%
  • Voltage Supply: 4.5V to 5.5V
  • Response Time: 4µs (typical)
  • Frequency: 120kHz
  • Package/Case: 16-SOIC (0.295", 7.50mm width)
  • Operating Temperature Range: -40°C to 125°C
  • Packaging: Tape and Reel
  • Standard Package: 1,000 units
  • Applications: Automotive and Industrial Systems
