ACS723KMATR-20AB-T Real Image ACS723KMATR-20AB-T Real Image
Same model may have multiple batches, images only for reference.
ACS723KMATR-20AB-T Real Image ACS723KMATR-20AB-T Real Image
ACS723KMATR-20AB-T Real Image ACS723KMATR-20AB-T Real Image
Same model may have multiple batches, images only for reference.

ACS723KMATR-20AB-T

Part No ACS723KMATR-20AB-T
Manufacturer Allegro MicroSystems, LLC
Catalog Current Sense Transformers
Description SENSOR CURRENT HALL 20A AC/DC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Allegro MicroSystems
Packaging Reel
For Measuring AC/DC
Sensor Type Hall Effect, Open Loop
Current - Sensing 20A
Number of Channels 1
Output Ratiometric, Voltage
Sensitivity 100mV/A
Frequency DC ~ 80kHz
Linearity ±1%
Accuracy ±2%
Supply Voltage (V) 4.5V ~ 5.5V
Response Time 5μs
Current - Supply (Maximum) 14mA
Temperature Range - Operating -40°C ~ 125°C
Polarization Bidirectional
Mounting Style SMD
Manufacturer Package 16-SOIC
Supplier Device Package 16-SOIC
Manufacturer Pack Quantity 1,000
MSL Level 3 (168 Hours)
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 810155-ACS723KMATR-20AB-T
Ultra Librarian 3D Model Ultra Librarian ACS723KMATR-20AB-T CAD Model

Description

The Allegro MicroSystems ACS723KMATR-20AB-T is a bidirectional current sensor.

  • Sensitivity: 100mV/A
  • Maximum Current Sensing: 20A
  • Sensor Type: Hall Effect open loop
  • Measurement: AC and DC
  • Output: Ratiometric, Voltage-based
  • Package: 16-SOIC
  • Temperature Range: -40°C to 125°C
  • Response Time: 5μs
  • Frequency Range: DC to 80kHz
  • Accuracy: ±2%
  • Linearity: ±1%
  • Supply Voltage: 4.5V to 5.5V
  • Maximum Current Supply: 14mA
  • Packaging: Reel
  • Pack Quantity: 1,000
