The AS7C164A-15JCN is a high-performance 64K x 1 Static Random Access Memory (SRAM) device manufactured by Alliance Memory, Inc. SRAMs are known for their fast access speeds and are widely used in applications demanding quick data storage and retrieval.

Applications

• Cache Memory: Used in processors and microcontrollers as cache memory to speed up data access.
• Networking Equipment: Employed in routers, switches, and network interface cards (NICs) for buffering data packets.
• Digital Signal Processing (DSP): Utilized in DSP systems for storing and processing real-time signals.
• Embedded Systems: Found in various embedded systems, including industrial controllers and medical devices, for temporary data storage.
• Test and Measurement Equipment: Used in oscilloscopes, logic analyzers, and signal generators for data capture and analysis.

Features

• High Speed: Features a fast access time of 15 ns.
• Low Power Consumption: Operates with low power consumption, suitable for battery-powered applications.
• Single 5V Power Supply: Requires a single 5V power supply for operation.
• TTL Compatible Inputs and Outputs: Compatible with TTL logic levels.
• Available in PDIP Package: Packaged in a plastic dual in-line package (PDIP) for easy through-hole mounting.
• Operating Temperature: Operates within a standard commercial temperature range.

Benefits

• Fast Data Access: Provides quick data storage and retrieval due to its fast access time.
• Low Power Consumption: Reduces power usage, prolonging battery life in portable devices.
• Easy Integration: Compatible with TTL logic for simple integration into existing systems.
• Reliable Performance: Offers dependable operation for critical data storage.
• Cost-Effective: Provides a cost-efficient solution for high-speed memory applications.

Additional Details

The AS7C164A-15JCN has a memory organization of 64K x 1 bit. It is designed for asynchronous operation. It features separate data input and output pins. The operating temperature range is 0°C to +70°C. The device is commonly used where a fast and reliable SRAM is required. The fast access time ensures quick read and write operations, crucial for real-time data processing. It is suitable for applications that require relatively small amounts of memory with very fast access times. The device simplifies memory system design in various applications where fast and reliable data storage is essential.
