AO3416L Alpha & Omega Semiconductor Inc. AO3416L Real Image AO3416L label picture
Same model may have multiple batches, images only for reference.
AO3416L Alpha & Omega Semiconductor Inc. AO3416L Real Image AO3416L label picture
AO3416L Alpha & Omega Semiconductor Inc. AO3416L Real Image AO3416L label picture
Same model may have multiple batches, images only for reference.

AO3416L

Part No AO3416L
Manufacturer Alpha & Omega Semiconductor Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 20V 6.5A SOT23
Datasheet
AO3416L Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Alpha & Omega Semiconductor Inc.
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 20V
Continuous Drain Current at 25°C 6.5A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 1.8V, 4.5V
Gate-Source Threshold Voltage 1V @ 250μA
Max Gate Charge 16nC @ 4.5V
Max Input Capacitance 1160pF @ 10V
Maximum Gate-Source Voltage ±8V
Power Dissipation (Max) 1.4W (Ta)
Maximum Rds On at Id,Vgs 22 mOhm @ 6.5A, 4.5V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-23-3L
Dimension TO-236-3, SC-59, SOT-23-3
Win Source Part Number 078094-AO3416L
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name AO3416
Introduction Date August 14, 2007
ECCN EAR99
Country of Origin China
Estimated EOL Date Obsolete
Ultra Librarian 3D Model Ultra Librarian AO3416L CAD Model

Description

AO3416L P-Channel MOSFET

The AO3416L is a specialized MOSFET transistor designed for efficient power management. Its low on-resistance and high-speed switching capabilities make it an ideal component in energy-conscious designs.

  • Features and Benefits:
    • Efficient thermal performance
    • Reliable switching speeds
    • Lower power dissipation
    • Optimized for compact devices
  • Applications:
    • Portable audio systems
    • Personal digital assistants
    • Camera-powered circuits
    • Power banks and chargers

Additional Details: Capable of handling -20V in drain-source voltage, the AO3416L is engineered to fit within the stringent power efficiency requirements of today’s modern devices.
