Products specifications

Categories Integrated Circuits
Manufacturer Altera
Status Active
Number of LABs/CLBs 1395
Number of Logic Elements/Cells 22320
Total RAM Bits 608256
Number of I/O 153
Supply Voltage - Operating 1.15 V to 1.25 V
Mounting SMD (SMT)
Temperature Range - Operating 0°C to 85°C (TJ)
Case / Package 256-FBGA (17x17)
Win Source Part Number 203794-EP4CE22F17C8N
Family Name EP4CE22
Introduction Date January 27, 2010
ECCN EAR99
Country of Origin Republic of Korea
Halogen Free Compliant
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian EP4CE22F17C8N CAD Model

Description

Overview

The EP4CE22F17C8N is a cutting-edge FPGA from Altera that caters to applications needing a robust performance framework with cost efficiency. This device is part of the Cyclone IV E series, recognized for its adaptability and cost-effectiveness.

Features and Benefits

  • 22K logic elements facilitating complex system designs.
  • 17mm x 17mm package for compact installations.
  • Versatile connectivity options with multiple I/O standards.
  • Cost-effective solution to optimize development expenses.

Applications

  • Broadcast and imaging systems
  • Network security devices
  • Video processing hardware
  • Customized computing solutions
  • Educational and research projects

Additional Details

Designed to address the needs of low-cost, high-performance applications, the EP4CE22F17C8N FPGA is essential for developers who require flexibility and reliability in their digital components.
