AZC199-02S.R7G Amazing
Same model may have multiple batches, images only for reference.

AZC199-02S.R7G

Part No AZC199-02S.R7G
Manufacturer Amazing
Catalog HOT - SALES and EOL Components (0 - A)
Description Low Capacitance High ESD Level Protection Array
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Amazing
Win Source Part Number 67001-AZC199-02S.R7G
Popularity Low
Supply and Demand Status Balance
Introduction Date June 21, 2016
ECCN EAR99
Estimated EOL Date 2030
Ultra Librarian 3D Model Ultra Librarian AZC199-02S.R7G CAD Model

Description

AZC199-02S.R7G - Precision ESD Protection Device

Designed for precision and effectiveness, the AZC199-02S.R7G is an essential component for protecting sensitive circuitry from ESD. Its application range is vast, accommodating various high-demand fields.

  • Applications/Projects:
    • Medical electronics
    • Computing devices
    • Smart home technology
  • Features and Benefits:
    • Precision diode technology for consistent ESD management
    • Compact and space-efficient design
    • Improved system reliability and longevity
  • Additional Details:
    • Wide operational temperature range
    • Adapts well to various circuit design requirements
