Same model may have multiple batches, images only for reference.
AZ2850-2A-12DE Real Image
Same model may have multiple batches, images only for reference.

AZ2850-2A-12DE

Part No AZ2850-2A-12DE
Manufacturer American Zettler, Inc.
Catalog Power Relays, Over 2 Amps
Description RELAY SOLAR DPST 40A 12V / Solar Relay DPST-NO (2 Form A) 12VDC Coil Through Hole
Datasheet
AZ2850-2A-12DE Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays - Power Relays, Over 2 Amps
Mfr American Zettler
Package Tray
Mounting Type Through Hole
Coil Voltage 12VDC
Contact Form DPST-NO (2 Form A)
Contact Rating (Current) 40 A
Switching Voltage 600VAC, 30VDC - Max
Coil Current 140 mA
Coil Type Non Latching
Termination Style PC Pin
Seal Rating Sealed - Fully
Coil Insulation Class F
Must Operate Voltage 9 VDC
Must Release Voltage 1.2 VDC
Operate Time 25 ms
Release Time 25 ms
Temperature Range - Operating -40°C ~ 85°C
Contact Material Silver Cadmium Oxide (AgCdO)
Relay Type Solar
Coil Resistance 86 Ohms
Base Product Number AZ2850
Standard Package 20
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.41.0050
Win Source Part Number 1338561-AZ2850-2A-12DE
Ultra Librarian 3D Model Ultra Librarian AZ2850-2A-12DE CAD Model

Description

The American Zettler Solar Relay is a DPST-NO (2 Form A) component that has a 12VDC coil and a through-hole mounting type.

  • Contact Form: DPST-NO (2 Form A)
  • Coil Voltage: 12VDC
  • Mounting Type: Through-Hole
  • Category: Power Relay Over 2 Amps
  • Seal Rating: Fully Sealed
  • Manufacturer: American Zettler, Inc.
  • Win Source Part Number: 1338561-AZ2850-2A-12DE
  • Description: It is a reliable and efficient component that is ideal for use in solar applications.
