AZSR250-2AE-12D

Name: AZSR250-2AE-12D
Brand: American Zettler, Inc.
SKU: 862844
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	AZSR250-2AE-12D
Manufacturer	American Zettler, Inc.
Catalog	Power Relays, Over 2 Amps
Description	RELAY EV CHRG SOLAR DPST 55A 12V
Datasheet	AZSR250-2AE-12D Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Relays - Power Relays, Over 2 Amps
Mfr	American Zettler, Inc.
Package	Box
Product Status	Active
Mounting Type	Through Hole
Coil Voltage	12VDC
Contact Form	DPST-NO (2 Form A)
Contact Rating (Current)	55 A
Switching Voltage	440VAC, 150VDC - Max
Coil Current	40 mA
Coil Type	Non Latching
Termination Style	Plug In
Coil Insulation	Class F
Must Operate Voltage	9 VDC
Must Release Voltage	0.6 VDC
Operate Time	40 ms
Release Time	5 ms
Temperature Range - Operating	-40°C ~ 85°C
Contact Material	Silver Tin Oxide (AgSnO)
Relay Type	EV Charging, Solar
Coil Resistance	300 Ohms
Base Product Number	AZSR250
Standard Package	10 pcs
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8536.41.0050
Win Source Part Number	862844-AZSR250-2AE-12D
Ultra Librarian 3D Model	Ultra Librarian AZSR250-2AE-12D CAD Model

Description

The AZSR250-2AE-12D power relay, manufactured by American Zettler, Inc., is a high-performance electronic component designed for demanding applications.

Application: EV Charging and Solar
Contact Form: Double-Pole, Single-Throw Normally Open (2 Form A)
Contact Material: Silver Tin Oxide (AgSnO)
Contact Rating: 55A
Coil Voltage: 12VDC
Coil Resistance: 300 Ohms
Temperature Range: -40°C to 85°C
Mounting Type: Through-Hole
Standard Package: 10 pieces
