AD586JNZ

Part No AD586JNZ
Manufacturer Analog Devices Inc.
Catalog PMIC - Voltage Reference
Description IC VREF SERIES 5V 8DIP
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Analog Devices Inc.
Packaging Tube
Reference Type Series
Output Type Fixed
Output Voltage 5V
Output Current 10mA
Tolerance ±0.4%
Temperature Coefficient 25ppm/°C
Noise - 0.1Hz to 10Hz 4μVp-p
Voltage - Input 10.8 V ~ 36 V
Operating Supply Current 3mA
Operating Temperature Range 0°C ~ 70°C (TA)
Mounting Style Through Hole
Package 8-DIP (0.300", 7.62mm)
Manufacturer Package 8-PDIP
Manufacturer Homepage www.analog.com
RoHS State Request Verification
Win Source Part Number 758670-AD586JNZ
Popularity Medium
Supply and Demand Status Limited
Family Name AD586
Introduction Date November 01, 1995
Country of Origin Philippines
Halogen Free Not Compliant
Estimated EOL Date 2030
Ultra Librarian 3D Model Ultra Librarian AD586JNZ CAD Model

Description

The AD586JNZ represents a pinnacle of precision voltage reference technology from Analog Devices Inc., a company renowned for its high-quality electronic components. This device is engineered to provide a stable and accurate reference voltage across a wide range of environmental conditions and applications.

Key Features

  • High Accuracy: The AD586JNZ offers a laser-trimmed accuracy that ensures minimal deviation, making it ideal for critical applications where precision is paramount.
  • Low Temperature Coefficient: With a temperature coefficient as low as 10 ppm/°C, users can rely on a consistent performance over a broad temperature range.
  • Output Voltage: This device provides a fixed output voltage of 5V, which is a common reference in many circuits and systems.
  • Wide Operating Range: The AD586JNZ operates efficiently with a supply voltage range from 4.5V to 30V, accommodating various supply requirements.
  • Low Noise: It features low output noise, making it suitable for sensitive electronic applications, including precision data converters and measurement devices.
  • High Load-Driving Capability: The device can source up to 10 mA of output current, allowing it to drive most reference inputs without additional buffering.

Applications

The AD586JNZ is versatile and can be used in a multitude of applications, including:

  • Precision data systems
  • High-resolution converters
  • Industrial instrumentation
  • Portable battery-powered devices
  • Calibration equipment

Product Specifications

Parameter Value
Output Voltage 5V ±0.15%
Temperature Coefficient 10 ppm/°C (max)
Load Regulation 0.1 mV/mA
Line Regulation 0.01%/V
Supply Voltage Range 4.5V to 30V
Output Current Capability 10 mA

With its robust design and exceptional performance, the AD586JNZ is an indispensable component for ensuring the integrity and accuracy of your electronic systems.
