Analog Devices Inc. AD7091R-4BCPZ-RL7

The AD7091R-4BCPZ-RL7 is a high-performance, ultra-low power, 12-bit analog-to-digital converter (ADC) offered by Analog Devices Inc., a leading global manufacturer of precision high-performance integrated circuits used in analog and digital signal processing applications.

This ADC is part of the AD7091R series and is characterized by its compact 10-lead LFCSP (Lead Frame Chip Scale Package) that measures just 3mm x 3mm, making it ideal for space-constrained applications. The AD7091R-4BCPZ-RL7 operates from a single 2.7 V to 5.25 V power supply and features a high-speed serial interface that is SPI-compatible, allowing for easy integration into a variety of microcontroller-based systems.

Key features of the AD7091R-4BCPZ-RL7 include:

• A throughput rate of 1 MSPS (Mega-Samples Per Second), enabling high-speed data acquisition.
• Ultra-low power consumption, with typical operating current of just 349 μA at 3 V and a power-down current of 0.5 μA, which is highly beneficial for battery-powered devices.
• High accuracy and low noise performance, which are essential for precision measurement applications.
• An internal 2.5 V reference that provides a simplified design process, as no external reference is needed.
• Four single-ended input channels, which allow the device to sample multiple analog signals, making it versatile for multi-channel applications.

With its exceptional performance, the AD7091R-4BCPZ-RL7 is well-suited for a wide range of applications, including battery-powered devices, data acquisition systems, medical instruments, and communications equipment. Its small size and low power consumption also make it an excellent choice for portable and remote sensing applications.

Analog Devices Inc. provides robust support for the AD7091R-4BCPZ-RL7 with comprehensive technical documentation, reference designs, and customer support, ensuring that integrating this ADC into your project is as straightforward as possible.

Whether you are designing a sophisticated medical device or a compact consumer electronic product, the AD7091R-4BCPZ-RL7 from Analog Devices Inc. offers a perfect blend of efficiency, precision, and size to meet your ADC requirements.
