AD7490BCPZ

Part No AD7490BCPZ
Manufacturer Analog Devices Inc.
Catalog Data Acquisition - Analog to Digital Converters (ADC)
Description 16-Channel, 1 MSPS, 12-Bit ADC with Sequencer in 28-Lead TSSOP
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Analog Devices Inc.
Packaging Tray
Resolution 12
Sampling Rate 1M
Number of Inputs 16
Input Type Single Ended
Data Interface SPI, DSP
Configuration MUX-S/H-ADC
Number of Converters 1
Architecture SAR
Reference Type External
Operating Supply Voltage 2.7 V ~ 5.25 V
Voltage - Supply, Digital 2.7 V ~ 5.25 V
Operating Temperature Range -40°C ~ 85°C
Package 32-VFQFN Exposed Pad, CSP
Manufacturer Package 32-LFCSP-VQ (5x5)
Win Source Part Number 1137267-AD7490BCPZ
Manufacturer Homepage www.analog.com
Popularity Medium
Supply and Demand Status Limited
Family Name AD7490
Introduction Date August 31, 2001
ECCN EAR99
Country of Origin Republic of Korea
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian AD7490BCPZ CAD Model

Description

AD7490BCPZ - 12-Bit SAR ADC from Analog Devices Inc.

The AD7490BCPZ is a high-performance, 12-bit successive approximation register (SAR) analog-to-digital converter (ADC) from Analog Devices Inc., an industry leader in high-precision data conversion technology. This ADC is designed for applications that require fast, accurate digital representations of analog signals, making it an ideal choice for data acquisition systems, medical instruments, and industrial control processes.

Key Features:

  • Resolution: The device offers a resolution of 12 bits, providing fine detail in the analog-to-digital conversion process.
  • Sampling Rate: With a maximum sampling rate of 1 MSPS (million samples per second), the AD7490BCPZ is well-suited for high-speed applications.
  • Input Channels: It features 16 single-ended input channels, which allows for multiple signal inputs without the need for additional multiplexing hardware.
  • Low Power Consumption: The ADC operates with a supply voltage from 2.7V to 5.25V and features a low power consumption design, making it suitable for battery-powered devices.
  • Interface: A serial interface is provided for data output, which can be easily connected to microcontrollers, DSPs, or FPGAs.
  • On-Chip Reference: An internal 2.5V reference voltage is included, which simplifies the design by eliminating the need for external reference components.
  • Package: The device comes in a compact 32-lead LFCSP (Lead Frame Chip Scale Package), which saves board space and is beneficial for space-constrained applications.

Applications:

The versatility of the AD7490BCPZ makes it an excellent choice for a wide array of applications, including:

  • Data Acquisition Systems
  • Medical Instruments such as ECG and EEG Monitors
  • Industrial Automation and Process Control
  • Battery-Powered Devices
  • Communication Systems

The AD7490BCPZ ADC from Analog Devices Inc. combines speed, precision, and low-power operation, making it a superior choice for engineers and designers looking to integrate reliable data conversion into their systems. With its easy-to-use interface and robust feature set, this ADC is poised to deliver top-notch performance in a variety of demanding applications.
