Product Overview: AD820BRZ-REEL7

The AD820BRZ-REEL7 is a high-performance, single-supply operational amplifier from Analog Devices Inc., designed to offer a blend of precision, low power consumption, and versatility. This operational amplifier is part of the renowned AD820 series, well-suited for a wide range of applications including sensors, instrumentation, and control systems.

Key Features

• Single-Supply Operation: The AD820BRZ-REEL7 is capable of operating from a single 5V to 36V supply or dual supplies of ±2.5V to ±18V, making it extremely flexible for various circuit configurations.
• Low Power Consumption: With its low supply current of 800μA max, this op-amp is an excellent choice for battery-powered and portable applications where power efficiency is critical.
• High Precision: It offers a low input offset voltage of 800μV max and an input offset voltage drift of only 2μV/°C max, ensuring high accuracy in measurement and control systems.
• Rail-to-Rail Output Swing: The output can swing rail-to-rail, which maximizes the dynamic range in single-supply applications.
• Low Input Bias Current: With an input bias current of 25nA max, it is suitable for applications requiring high input impedance and minimal error due to bias current.
• No Phase Reversal: The AD820BRZ-REEL7 is designed to prevent phase reversal with overdriven inputs, providing stable operation for control systems.

Package and Quality

The AD820BRZ-REEL7 comes in a compact SOIC-8 package, making it easy to integrate into space-constrained designs. The device is supplied on a 7-inch reel, which is ideal for automated manufacturing processes. Analog Devices Inc. ensures that this op-amp meets rigorous quality standards, providing reliable performance in industrial and commercial applications.

Applications

This operational amplifier is versatile and can be used in a variety of applications, such as:

• Portable and battery-powered equipment
• Data acquisition systems
• Medical instrumentation
• Sensor signal conditioning
• Active filters
• Audio electronics

With its combination of features, the AD820BRZ-REEL7 from Analog Devices Inc. offers engineers a robust and efficient solution for precision amplification requirements.
