The AD8210YRZ-REEL7 is a high bandwidth, precision fixed gain, bidirectional current sense amplifier from Analog Devices Inc., a leading global semiconductor company known for their innovative design and manufacturing of analog, mixed-signal, and DSP integrated circuits.

Key Features

• Fixed Gain: The device features a fixed gain of 20 V/V, providing a precise amplification of the sensed current signal without the need for external gain setting components.
• High Bandwidth: With a bandwidth of 450 kHz, the AD8210YRZ-REEL7 is capable of monitoring fast-changing current signals, making it suitable for high-performance applications.
• Bidirectional Sensing: This amplifier can measure both positive and negative current flow, offering versatility in various monitoring scenarios.
• Wide Supply Range: It operates with a supply voltage range from 4.5 V to 5.5 V, accommodating a variety of industrial and automotive power systems.
• High Accuracy: The device maintains high accuracy and low offset voltage, ensuring reliable current measurements for critical applications.
• Overcurrent Detection: Features an integrated overcurrent detection flag that can be used for system protection or diagnostics.
• Robust Design: The AD8210YRZ-REEL7 is designed to withstand harsh automotive environments and is qualified for use in these conditions.

Applications

The amplifier is ideal for a range of applications including but not limited to:

• Automotive battery management systems
• Motor control
• Power management
• Overcurrent protection circuits
• Data acquisition systems

Quality and Reliability

Analog Devices Inc. ensures that the AD8210YRZ-REEL7 meets the highest standards of quality and reliability. The device is available in a compact surface-mount package and is provided in reel format for automated assembly processes, facilitating efficient manufacturing and integration into a variety of electronic systems.

Ordering Information

The product is available with the ordering part number AD8210YRZ-REEL7, which indicates the device is provided in a 7-inch reel suitable for automated pick-and-place equipment, optimizing production scalability and efficiency.
