AD8541AKSZ-REEL7

Part No AD8541AKSZ-REEL7
Manufacturer Analog Devices Inc.
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP GP 1MHZ RRO SC70-5
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Analog Devices Inc.
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 1
Output Type Rail-to-Rail
Slew Rate 0.92 V/μs
Gain Bandwidth Product (GBP) 1MHz
Current - Input Bias 4pA
Voltage - Input Offset 1mV
Operating Supply Current 45μA
Channel Output Current 30mA
Supply Voltage - Operating 2.7 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package SC-70-5
Win Source Part Number 008492-AD8541AKSZ-REEL7
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian AD8541AKSZ-REEL7 CAD Model

Description

AD8541AKSZ-REEL7 - Precision CMOS Operational Amplifier

The AD8541AKSZ-REEL7 is a high-performance, single-supply operational amplifier from Analog Devices Inc., designed to offer precision and low power consumption in a compact SOT-23-5 package. This device is a part of the AD8541 family, which is renowned for its excellent performance in battery-powered applications due to its low power draw and wide supply voltage range.

Key Features

  • Supply Voltage Range: The AD8541AKSZ-REEL7 operates on a supply voltage range of 2.7V to 5.5V, making it versatile for both 3V and 5V systems.
  • Low Power Consumption: With a quiescent current of just 45 µA, this op-amp is an excellent choice for power-sensitive applications.
  • Rail-to-Rail Output: The rail-to-rail output stage ensures maximum dynamic range, which is particularly beneficial in low-voltage applications.
  • Input Voltage Range: This amplifier can handle input voltages that range from 0.3V below the negative rail to 1.2V above the positive rail, providing increased flexibility in circuit design.
  • Bandwidth and Slew Rate: It has a gain bandwidth product of 1 MHz and a slew rate of 0.8 V/µs, balancing the needs of speed and power efficiency.
  • Low Input Bias Current: The input bias current is extremely low, typically 1 pA, which is ideal for high impedance sensor applications.
  • Packaging: Supplied in a 5-lead SOT-23-5 package, the AD8541AKSZ-REEL7 is suitable for space-constrained applications.

Applications

The AD8541AKSZ-REEL7 is well-suited for a wide range of applications, including but not limited to:

  • Portable and battery-powered electronics
  • Test and measurement equipment
  • Sensor interfaces
  • Medical devices
  • Audio equipment
  • Analog filters
  • Notebooks and PDAs

With its combination of low power consumption, precision performance, and compact form factor, the AD8541AKSZ-REEL7 operational amplifier from Analog Devices Inc. is an excellent choice for designers looking to enhance the efficiency and reliability of their electronic systems.
