The ADF4116BRUZ is a high-performance frequency synthesizer that utilizes a phase-locked loop (PLL) with an integrated voltage-controlled oscillator (VCO). Manufactured by Analog Devices Inc., a leader in precision high-performance integrated circuits, this component is designed to generate a broad range of frequencies with excellent phase noise performance.

Key Features

• Frequency Range: The ADF4116BRUZ is capable of operating at frequencies up to 6 GHz, making it suitable for a wide variety of applications including wireless communication, instrumentation, and aerospace systems.
• Programmable Divider: It includes a programmable dual-modulus prescaler, as well as programmable charge pump currents and counter operation, offering flexibility in system design.
• Low Phase Noise: With its low phase noise characteristics, this synthesizer ensures a clean signal for high-quality communication and precise measurements.
• Power Supply: The device operates on a 2.7V to 5.5V power supply, accommodating various system power requirements.
• Package: Packaged in a compact TSSOP-16 (ADFs standard 0.5mm pitch TSSOP), the ADF4116BRUZ is designed for space-saving on printed circuit boards (PCBs).

Applications

The versatility of the ADF4116BRUZ makes it ideal for a multitude of applications. It is particularly well-suited for:

• Wireless communication systems including GSM, PCS, DCS, 3G, and WLAN
• Base stations, wireless LANs, and broadband access networks
• Test and measurement equipment
• PLLs in radio, aerospace, and satellite communications

Technical Specifications

The ADF4116BRUZ offers a comprehensive set of technical specifications that ensure its adaptability and performance in demanding environments:

For engineers and designers looking for a reliable and flexible frequency synthesizer, the ADF4116BRUZ from Analog Devices Inc. provides a powerful solution that meets a broad range of frequency generation needs.
