Product Overview: ADG1408YRUZ-REEL7

The ADG1408YRUZ-REEL7 is a high-performance, monolithic analog multiplexer from Analog Devices Inc., a leader in the design and manufacturing of high-precision integrated circuits. This product is part of the robust ADG1408 series, which offers exceptional signal integrity and reliability for a wide range of applications.

Key Features

• Channel Configuration: The ADG1408YRUZ-REEL7 features an 8:1 single-channel multiplexer, allowing users to select one of eight inputs to connect to a single output. This flexibility makes it ideal for various data acquisition and test and measurement applications.
• Low On-Resistance: This device boasts a low on-resistance (RON) typically around 4.5 ohms, ensuring minimal signal attenuation and distortion when the switch is closed.
• Single Supply Operation: It operates from a single 5 V to 16.5 V power supply or a dual ±5 V power supply, providing versatility in different circuit configurations.
• Fast Switching Times: The ADG1408YRUZ-REEL7 provides fast transition times (tON and tOFF) in the order of nanoseconds, which is crucial for applications requiring quick signal routing.
• Low Power Consumption: With its efficient design, the device consumes minimal power, making it suitable for power-sensitive applications.
• Extended Temperature Range: It is rated for operation over the extended industrial temperature range of -40°C to +125°C, ensuring reliable performance under harsh conditions.
• Package and Availability: The device comes in a compact TSSOP-16 package and is supplied in 7-inch reels, facilitating ease of integration into automated manufacturing processes.

Applications

The ADG1408YRUZ-REEL7 is designed for use in a variety of systems where high-performance signal routing is required. Common applications include:

• Data acquisition systems
• Audio and video switching
• Automatic test equipment
• Communication systems
• Relay replacement
• Medical instrumentation

Quality and Reliability

Analog Devices Inc. is renowned for its commitment to quality and reliability. The ADG1408YRUZ-REEL7 is built to meet the highest standards, ensuring stable and dependable operation in even the most demanding environments.

For more detailed specifications and application notes, customers are encouraged to review the product datasheet and consult with Analog Devices' technical support team for tailored advice on integrating this multiplexer into their projects.
