The ADG412BRZ is a high-performance monolithic quad single pole single throw (SPST) switch manufactured by Analog Devices Inc. This component is designed to deliver precision and reliability for a wide range of applications, including data acquisition systems, communication systems, and medical equipment.

Key Features

• Low On Resistance: The ADG412BRZ features a low on resistance (R_ON), typically around 35 ohms, which remains flat over the full analog signal range. This characteristic ensures minimal signal distortion and provides excellent linearity.
• Low Power Consumption: With a power consumption of less than 5 µW, the ADG412BRZ is an energy-efficient solution, making it ideal for portable and battery-powered applications.
• Single or Dual Supply Operation: It is capable of operating from a single +12 V to +30 V or dual ±5 V to ±20 V power supplies, offering flexibility in various circuit designs.
• High Switching Speed: The switch transition times are fast, with t_ON typically at 175 ns and t_OFF at 145 ns, which is suitable for applications requiring quick signal routing.
• Break-Before-Make Switching: This feature ensures that signal discontinuity is minimized by breaking the connection with the previous channel before making a connection with the next one.

Product Specifications

The ADG412BRZ is available in a robust 16-Lead SOIC package, ensuring ease of integration into various circuit designs. Its operating temperature range from -40°C to +85°C allows for reliable performance in harsh environments. With excellent on-resistance matching between channels and low total harmonic distortion, the ADG412BRZ is a top choice for designers looking for high-quality analog switching solutions.

Whether for precision instrumentation, sample-and-hold circuits, or audio signal routing, the ADG412BRZ from Analog Devices Inc. offers the performance and reliability necessary to meet the stringent requirements of modern electronic systems.
