Analog Devices Inc. ADG712BRU: CMOS Low Voltage 4/8 Channel Multiplexers

The ADG712BRU from Analog Devices Inc. is a high-performance CMOS analog multiplexer, offering a comprehensive solution for routing analog signals in a wide array of electronic systems. This device is particularly designed for low voltage operations, making it an ideal choice for battery-powered portable devices, as well as for applications that require efficient power management.

Key Features:

• Multiple Channel Configurations: The ADG712BRU is versatile with its dual 4-channel or single 8-channel multiplexer configuration. This allows for flexible usage in different circuit designs, providing designers with a range of options to best suit their application needs.
• Low Voltage Operation: Operating from a single 1.8V to 5.5V power supply, the ADG712BRU is optimized for low voltage systems, ensuring minimal power consumption without sacrificing performance.
• Low On Resistance: With an on resistance typically less than 4 ohms, this multiplexer ensures a high level of signal integrity, minimizing the impact on the signal path and thus maintaining the quality of the transmitted signal.
• Low Crosstalk and Off Isolation: The device features excellent crosstalk and off isolation performance, which is crucial for applications that require precise signal routing without interference from adjacent channels.
• Fast Switching Times: Fast transition times for turning on and off channels make the ADG712BRU suitable for applications that require rapid signal switching, such as data acquisition systems and test equipment.
• TTL/CMOS-Compatible Inputs: The logic control inputs are compatible with TTL and CMOS levels, thus allowing for easy integration with digital systems.

Applications:

With its robust feature set, the ADG712BRU is well-suited for a variety of applications, including:

• Data acquisition systems
• Communication systems
• Audio and video signal routing
• Relay replacement
• Industrial control systems
• Portable instrumentation

The ADG712BRU is offered in a TSSOP-16 package, providing a compact footprint for space-constrained applications. Its reliability and performance make it a go-to component for designers looking to create efficient, high-performing electronic systems.
