ADG712BRUZ-REEL by Analog Devices Inc.

The ADG712BRUZ-REEL is a high-performance CMOS analog multiplexer from Analog Devices Inc., a leader in the semiconductor industry. This device comes in a compact TSSOP (Thin Shrink Small Outline Package) form factor, offering a robust solution for routing analog signals in a wide range of applications including data acquisition systems, communication systems, and industrial process controls.

Key Features

• Low On Resistance: The ADG712BRUZ-REEL boasts a low on resistance (typically 4 ohms), ensuring minimal signal attenuation and preserving signal integrity.
• Single Supply Operation: This multiplexer operates from a single 1.8V to 5.5V supply, making it versatile for various circuit designs and compatible with a range of logic families.
• Low Power Consumption: With a low power consumption design, it is ideal for battery-powered and portable devices, ensuring energy efficiency.
• Dual 4:1 Multiplexer Configuration: The device features a dual 4:1 multiplexer configuration, allowing the connection of one of four inputs to each output, providing flexibility in signal routing.
• Fast Switching Times: Fast switching times (tON and tOFF) of the ADG712BRUZ-REEL ensure quick response times in critical applications, making it suitable for high-speed signal processing.
• ESD Protection: It includes enhanced electrostatic discharge (ESD) protection, safeguarding the device against static damage during handling and operation.
• Lead-Free and RoHS Compliant: The product is lead-free and compliant with the Restriction of Hazardous Substances (RoHS) directive, making it an environmentally friendly choice for electronic designs.

Applications

The versatility of the ADG712BRUZ-REEL allows it to be used in a variety of applications, such as:

• Test Equipment
• Audio and Video Switching
• Data Acquisition Systems
• Communication Systems
• Relay Replacement
• Industrial Process Controls

With its mix of performance and reliability, the ADG712BRUZ-REEL from Analog Devices Inc. stands out as a top choice for designers looking to optimize their analog signal routing with a high-quality, efficient, and flexible solution.
