Product Overview: ADG714BRUZ-REEL7

The ADG714BRUZ-REEL7 is a high-performance CMOS analog multiplexer from Analog Devices Inc., offering exceptional signal integrity and ease of use. This product is part of the ADG714 series, which is known for its robust design and reliable performance in a variety of applications. The device comes in a compact TSSOP-20 package, making it ideal for space-constrained applications.

Key Features

• Channel Configuration: The ADG714BRUZ-REEL7 features an 8-channel, double-pole, single-throw (8 × DPST) switch configuration. This allows for greater flexibility in signal routing and provides the ability to control multiple signal paths with a single device.
• Low On Resistance: With a typical on resistance of just 4 ohms, this multiplexer ensures minimal signal attenuation, providing a high-fidelity signal path for precision applications.
• Wide Supply Voltage Range: The device operates across a wide supply voltage range of ±2.7 V to ±5.5 V, allowing it to be used in both single and dual supply operations for maximum versatility.
• Low Power Consumption: The ADG714BRUZ-REEL7 boasts low power consumption, making it suitable for battery-powered and portable devices where power efficiency is critical.
• High ESD Protection: Enhanced electrostatic discharge (ESD) protection is built into the device, safeguarding it against the damaging effects of static electricity and enhancing its reliability in harsh environments.

Applications

The ADG714BRUZ-REEL7 is well-suited for a variety of applications, including:

• Data acquisition systems
• Communication systems
• Audio and video signal routing
• Relay replacement
• Industrial control systems

Its high-performance characteristics make it an excellent choice for designers looking for a reliable multiplexer that can handle multiple signals without compromising on signal quality. Whether used in professional-grade audio equipment, precision data systems, or robust industrial controls, the ADG714BRUZ-REEL7 from Analog Devices Inc. delivers the performance and reliability needed for today's demanding applications.

Quality and Packaging

The ADG714BRUZ-REEL7 is available in a reel package for automated assembly processes, ensuring a reliable supply for mass production requirements. Analog Devices Inc. is known for its commitment to quality, and this product is no exception, meeting stringent industry standards for performance and reliability.
