Product Overview: ADG801BRTZ-500RL7 by Analog Devices Inc.

The ADG801BRTZ-500RL7 is a high-performance CMOS analog switch from Analog Devices Inc., designed to deliver exceptional signal integrity and reliability for a wide range of applications. This switch is part of the ADG801 series, which is renowned for its low on-resistance and single-supply operation, making it an ideal choice for precision analog switching.

Key Features

• Low On-Resistance: The ADG801BRTZ-500RL7 boasts an ultra-low on-resistance of typically 0.5 ohms, ensuring minimal signal distortion and power loss.
• Single-Supply Operation: Operating from a single 1.8V to 5.5V supply, this switch is versatile and can be easily integrated into a variety of systems without the need for dual supplies.
• Fast Switching Times: With t<sub>ON of 20 ns and t<sub>OFF of 10 ns, the device provides rapid switching, making it suitable for high-speed applications.
• Low Power Consumption: The ADG801BRTZ-500RL7 has a low power consumption, with a typical supply current of less than 1µA, which is ideal for power-sensitive designs.
• Wide Operating Temperature Range: This switch is designed to operate over an extended temperature range from -40°C to +125°C, ensuring reliable performance in harsh environments.

Applications

The ADG801BRTZ-500RL7 is suitable for a variety of applications, including:

• Audio and video signal routing
• Data acquisition systems
• Communication systems
• Relay replacement
• Battery-powered systems

Package and Quality

The device is packaged in a compact SOT-23-6, making it suitable for space-constrained applications. The part number ADG801BRTZ-500RL7 indicates that the device is provided in a tape and reel format with 500 units per reel, which facilitates efficient assembly processes for high-volume production.

Analog Devices Inc. is known for its commitment to quality, and the ADG801BRTZ-500RL7 is no exception. It is manufactured to meet high standards, ensuring consistent performance and reliability for critical applications.

In summary, the ADG801BRTZ-500RL7 analog switch from Analog Devices Inc. offers a mix of low on-resistance, fast switching, single-supply operation, and low power consumption, making it a versatile choice for designers looking for a reliable switching solution.
