ADM485JRZ-REEL7: High-Speed, Low-Power Transceiver from Analog Devices Inc.

The ADM485JRZ-REEL7 is a high-performance differential line transceiver from the renowned manufacturer, Analog Devices Inc., designed to facilitate bidirectional data communications on multipoint bus transmission lines. It is a part of the ADM485 family, which is known for its reliability and efficiency in various applications, including industrial control, data acquisition systems, and other serial communication protocols that require high-speed and low-power operation.

Key Features

• Interface Type: RS-485/RS-422
• Data Rate: Up to 5 Mbps
• Supply Voltage: 5V
• Operating Temperature Range: -40°C to +85°C
• Power Consumption: Low power design
• ESD Protection: ±15kV on the bus pins
• Package: 8-SOIC (0.154", 3.90mm Width)
• Mounting Type: Surface Mount
• RoHS Status: RoHS compliant

Product Description

The ADM485JRZ-REEL7 is crafted for optimized power consumption and high-speed operation, supporting data rates up to 5 Mbps. This transceiver operates from a single 5V power supply and features a 1/8-unit load receiver input impedance. This allows up to 256 transceivers on the bus, making it an excellent choice for networked devices in complex systems.

Its robust design includes ESD protection of ±15kV on the bus pins to prevent damage from electrostatic discharges. Furthermore, the device's thermal shutdown and short-circuit protection ensure safe operation under fault conditions. The extended temperature range of -40°C to +85°C allows the ADM485JRZ-REEL7 to perform reliably in diverse environments.

The ADM485JRZ-REEL7 comes in an 8-SOIC package, suitable for surface mount technology (SMT), and is supplied in tape and reel form for use in automated manufacturing processes. Compliance with RoHS standards ensures that the product meets the latest environmental regulations, making it a responsible choice for electronic designs.

Whether you are designing a sophisticated industrial control system, a robust data acquisition unit, or a reliable communication interface, the ADM485JRZ-REEL7 transceiver from Analog Devices Inc. offers a perfect blend of high-speed performance, low power consumption, and superior protection features.
