ADM6320CX29-ARJZ-R7

Part No ADM6320CX29-ARJZ-R7
Manufacturer Analog Devices Inc.
Catalog Hard To Find
Description Supervisory Circuits with Watchdog and Manual Reset in 5-Lead SOT-23
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Analog Devices Inc.
Win Source Part Number 1140862-ADM6320CX29-ARJZ-R7
Manufacturer Homepage www.analog.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ADM6320CX29-ARJZ-R7 CAD Model

Description

ADM6320CX29-ARJZ-R7: A High-Precision Supervisory IC from Analog Devices Inc.

The ADM6320CX29-ARJZ-R7 is a robust supervisory circuit designed by Analog Devices Inc., a leader in the semiconductor industry known for their high-performance analog, mixed-signal, and digital signal processing (DSP) integrated circuits (ICs). This particular product is engineered to monitor power supplies in microprocessor systems, providing a high degree of precision and reliability.

With its compact SOT-23 package, the ADM6320 is an ideal solution for space-constrained applications. It offers a precise monitoring voltage threshold of 2.93V, tailored for systems that require a specific voltage supervision to ensure accurate operation. The device's reset output remains asserted for a minimum of 140ms after the supply voltage has risen above the reset threshold level, ensuring a proper system reset and giving the power supply and processor adequate time to stabilize.

The ADM6320CX29-ARJZ-R7 features a manual reset input, which provides an external override of the reset signal, allowing for a system reset without the need for cycling the power. This can be particularly useful for system maintenance or software updates that require a system reboot.

Key features of the ADM6320CX29-ARJZ-R7 include:

  • Watchdog timer for system reliability enhancement
  • Low supply current of 13μA, making it suitable for battery-powered applications
  • Guaranteed reset output from VCC = 1.1V
  • Power supply transient immunity, ensuring stable operation during supply fluctuations

This supervisory IC is an excellent choice for managing microprocessor systems in a wide range of applications, from automotive and industrial systems to portable and wireless devices. Its high accuracy and reliability ensure that systems are protected from undervoltage conditions, thereby enhancing overall system stability and performance.

The ADM6320CX29-ARJZ-R7 by Analog Devices Inc. is a testament to the company's commitment to delivering high-quality components that meet the stringent requirements of modern electronic systems. It is a testament to Analog Devices' expertise in creating solutions that enhance the performance and reliability of electronic systems across various industries.
