Analog Devices Inc. ADP7182ACPZ-R7: Ultra-Low Noise, CMOS, Linear Regulator

The ADP7182ACPZ-R7 is a high-performance linear regulator from Analog Devices Inc., designed to deliver a superior level of voltage regulation for sensitive RF and analog circuitry. This device provides a stable and precise output voltage, making it an ideal choice for applications that require a low noise power supply.

Key Features

• Ultra-Low Noise Output: With its advanced design, the ADP7182ACPZ-R7 offers an exceptionally low noise performance, which is crucial for maintaining signal integrity in sensitive applications.
• Wide Input Voltage Range: This regulator supports an input voltage range from 2.2 V to 20 V, providing flexibility in various system designs and ensuring compatibility with a broad range of input sources.
• Adjustable Output Voltage: The output voltage can be adjusted from 1.2 V to 19.5 V via external resistors, allowing for precise tuning to meet specific circuit requirements.
• High Output Current: Capable of delivering up to 200 mA of output current, the ADP7182ACPZ-R7 can power a wide array of devices and circuits without compromising performance.
• Low Dropout Voltage: The low dropout voltage feature ensures efficient operation, even when the input voltage is close to the output voltage, thereby minimizing power loss.
• Thermal Overload Protection: The built-in thermal overload protection safeguards the device against excessive power dissipation, which could otherwise lead to overheating and potential damage.
• Package Type: Available in a compact LFCSP (Lead Frame Chip Scale Package), the ADP7182ACPZ-R7 is suitable for space-constrained applications.

Applications

The ADP7182ACPZ-R7 is particularly well-suited for powering precision analog devices such as high-resolution ADCs, DACs, and PLLs. It is also an excellent choice for RF applications, medical equipment, and instrumentation where power supply noise can adversely affect performance. Furthermore, its robust feature set makes it a reliable option for automotive electronics, battery-powered devices, and portable communications equipment.

As part of Analog Devices Inc.'s commitment to high-quality components, the ADP7182ACPZ-R7 is a testament to their expertise in power management solutions. Whether you're designing for sensitive audio equipment or looking to enhance the performance of your high-speed digital systems, this linear regulator is engineered to meet the stringent requirements of a wide range of electronic applications.
