Product Overview: ADP7182AUJZ-5.0-R7 by Analog Devices Inc.

The ADP7182AUJZ-5.0-R7 is a high-precision, low-noise, CMOS linear regulator that offers a fixed 5.0V output voltage, housed in a compact TSOT-5 package. Manufactured by Analog Devices Inc., a leader in high-performance analog technology, this regulator is designed to meet the stringent requirements of sensitive RF and analog circuits, providing a stable and clean power supply.

Key Features

• Output Voltage: Fixed 5.0V with high accuracy.
• Low Dropout Voltage: Ensures efficient operation even with minimal difference between input and output voltages.
• Low Noise: With an ultra-low output noise of less than 10 µVrms over a 10 Hz to 100 kHz bandwidth, it is ideal for noise-sensitive applications.
• High PSRR: Excellent power supply rejection ratio (PSRR) that minimizes variations in output voltage due to changes in the input voltage.
• Current & Thermal Limiting: Built-in protection features such as overcurrent protection and thermal overload protection safeguard the device and the downstream circuitry from damage.
• Stable with Low ESR Capacitors: Stable with ceramic output capacitors that have low equivalent series resistance (ESR), which are smaller, more reliable, and have a longer lifespan than tantalum capacitors.

Applications

With its precision and low noise characteristics, the ADP7182AUJZ-5.0-R7 is well-suited for a variety of applications, including:

• Precision analog and RF instrumentation
• Medical devices and healthcare products
• Portable and battery-powered equipment
• Data acquisition systems
• Communications infrastructure

Quality and Reliability

Analog Devices Inc. is renowned for its commitment to quality and reliability, and the ADP7182AUJZ-5.0-R7 is no exception. Each device undergoes rigorous testing to ensure it meets the high standards expected from Analog Devices products. This linear regulator is a dependable choice for engineers and designers looking to enhance the performance of their power management systems.

For detailed technical specifications, application notes, and support resources, please refer to the official Analog Devices Inc. website or contact their customer support for further assistance.
