ADV7511KSTZ High-Definition Multimedia Interface (HDMI) Transmitter

The ADV7511KSTZ from Analog Devices Inc. is a high-performance High-Definition Multimedia Interface (HDMI) transmitter designed for audio and video applications that require high-definition content transmission. This integrated circuit is part of Analog Devices' comprehensive range of audio and video solutions, which are known for their reliability and cutting-edge performance.

The ADV7511KSTZ is encapsulated in a compact LQFP-100 package, making it suitable for space-constrained applications. It is capable of transmitting video resolutions up to 1080p and computer resolutions up to UXGA (1600 x 1200 @ 60 Hz). With an integrated HDCP (High-bandwidth Digital Content Protection) engine, it ensures secure transmission of protected content, adhering to the latest standards for content protection.

This HDMI transmitter supports 8-channel I2S audio, allowing for high-fidelity audio streaming alongside the video. Additionally, it supports S/PDIF (Sony/Philips Digital Interface) for compressed audio, making it versatile for various digital audio formats.

Key features of the ADV7511KSTZ include:

• 165 MHz HDMI transmitter
• Deep Color support up to 36 bits per pixel
• 3D video support
• Consumer Electronics Control (CEC) hardware support
• On-chip EDID RAM
• Low power operation
• Integrated HDCP engine with internal key storage
• Programmable AVI InfoFrame

The device is programmable through an I2C-compatible serial interface, which allows for a high level of customization to meet specific application requirements. The ADV7511KSTZ operates over an extended temperature range, making it suitable for various environments and applications such as digital signage, home theater systems, gaming consoles, and professional AV equipment.

Analog Devices Inc. provides extensive technical support and documentation for the ADV7511KSTZ, ensuring that designers can implement this HDMI transmitter into their products with confidence and efficiency. With its robust feature set and proven performance, the ADV7511KSTZ is an ideal choice for delivering high-quality, high-definition multimedia experiences.
