HMC1060LP3E

Part No HMC1060LP3E
Manufacturer Analog Devices Inc.
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LINEAR POS ADJ 16QFN
Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Voltage Regulators - Linear
Mfr Analog Devices Inc.
Package Strip
Product Status Obsolete
Output Configuration Positive
Output Type Adjustable
Number of Regulators 4
Voltage - Input (Max) 5.6V
Voltage - Output (Min/Fixed) 1.8V
Voltage - Output (Max) 5.2V
Current - Output 100mA, 50mA, 300mA, 500mA
Current - Quiescent (Iq) 2.1 mA
PSRR 80dB ~ 52dB (1kHz ~ 10MHz)
Control Features Enable
Protection Features Over Temperature
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Surface Mount
Package / Case 16-VFQFN Exposed Pad
Supplier Device Package 16-QFN (3x3)
Base Product Number HMC1060
Standard Package 1 pcs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 598409-HMC1060LP3E
Ultra Librarian 3D Model Ultra Librarian HMC1060LP3E CAD Model

Description

The HMC1060LP3E is a state-of-the-art Power Management Integrated Circuit (PMIC) designed and manufactured by the renowned Analog Devices Inc. This advanced component is engineered to cater to the demanding needs of modern electronic systems, providing efficient power regulation, system management, and a suite of protective features to ensure the longevity and reliability of your applications.

Key Features

  • High Efficiency: The HMC1060LP3E is optimized for high efficiency, which is crucial for reducing heat dissipation and increasing the battery life of portable devices.
  • Multiple Output Channels: This PMIC features multiple regulated output channels, allowing for simultaneous power supply to different parts of the system with varying voltage requirements.
  • Programmable Voltage Levels: Users can program the output voltage levels to match specific needs, providing versatility and customization for a wide range of applications.
  • Low Quiescent Current: The device is designed with a low quiescent current to minimize power consumption when the system is in standby mode, further extending battery life in portable applications.
  • Thermal Protection: Built-in thermal protection safeguards the device and the system from damage due to overheating, ensuring safe operation under various conditions.
  • Small Package: The HMC1060LP3E comes in a compact 3x3 mm QFN package, making it suitable for space-constrained applications without compromising performance.

Applications

The versatility of the HMC1060LP3E makes it an ideal choice for a broad spectrum of applications, including but not limited to:

  • Portable and battery-powered devices
  • Wireless infrastructure
  • Automotive systems
  • Medical equipment
  • Industrial and automation systems

With its impeccable design and robust feature set, the HMC1060LP3E by Analog Devices Inc. represents a top-tier solution for power management challenges in today's sophisticated electronic systems. Integrating this PMIC into your design will not only streamline power delivery but also enhance the overall system performance and reliability.
