Product Overview: HMC485MS8G from Analog Devices Inc.

The HMC485MS8G is a high-performance, GaAs PHEMT MMIC Amplifier designed and manufactured by Analog Devices Inc. This versatile amplifier is well-suited for a range of applications including test equipment, military, and space as well as telecommunications infrastructure. With its robust design and state-of-the-art performance, the HMC485MS8G is engineered to meet the rigorous demands of modern electronic systems.

Key Features

• Frequency Range: The HMC485MS8G operates over a wide frequency range from 2 GHz to 22 GHz, making it an excellent choice for a variety of RF and microwave applications.
• Gain: It offers a high gain of 13 dB which is beneficial for signal amplification in complex systems.
• Output Power: The P1dB output power at 22 GHz is 19 dBm, ensuring strong signal transmission even at high frequencies.
• Supply Voltage: A single positive supply voltage of +5V is required for operation, simplifying the power supply design.
• Package: The device comes in an MSOP8G package, which is compact and suitable for space-constrained applications.

Applications

• Fiber Optic Systems
• Point-to-Point and Point-to-Multipoint Radios
• Test Equipment and Sensors
• Military and Space
• Telecommunications Infrastructure

Quality and Reliability

Analog Devices Inc. is known for its commitment to quality and the HMC485MS8G is no exception. It is built to the highest standards to ensure reliable operation under various conditions. Whether it's for a mission-critical military application or a high-precision test system, this amplifier is designed to perform consistently and effectively.

Support and Resources

Comprehensive technical support and resources are available for the HMC485MS8G, including detailed datasheets, application notes, and reference designs. Analog Devices Inc. provides extensive support to help integrate this amplifier into your design with ease.
