Product Overview: HMC948LP3ETR by Analog Devices Inc.

The HMC948LP3ETR is a high-performance, versatile RF mixer product from Analog Devices Inc., designed to meet the demanding requirements of communication and sensing systems. This particular model comes in a compact 3x3 mm QFN leadless package, making it an ideal solution for space-constrained applications without compromising on functionality or performance.

Key Features

• Wide Frequency Range: The device operates over a broad frequency spectrum, providing users with the flexibility to use it in various applications such as satellite communications, test equipment, and broadband receivers and transmitters.
• High Isolation: It features excellent LO to RF and LO to IF isolation, minimizing leakage and ensuring clean signal mixing.
• Low Conversion Loss: The HMC948LP3ETR boasts a low conversion loss, thereby maintaining signal integrity and reducing the need for additional amplification.
• Passive Double-Balanced Mixer: As a passive double-balanced mixer, it offers a good balance between linearity and conversion efficiency, making it suitable for both upconversion and downconversion applications.
• Leadless Package: The QFN package is not only space-saving but also provides excellent thermal performance, ensuring the device operates reliably over a wide temperature range.

Applications

The HMC948LP3ETR is engineered to serve a variety of industries and applications. Its robust design and high performance make it particularly well-suited for:

• Point-to-point and point-to-multipoint radios
• Military and space applications
• Wireless infrastructure
• Test instrumentation
• RF and IF applications

Technical Specifications

Some of the technical highlights of the HMC948LP3ETR include:

• Frequency Range: IF: DC to 3 GHz, LO/RF: 6 to 10 GHz
• Conversion Loss: 9 dB typical
• LO to RF Isolation: 45 dB typical
• LO to IF Isolation: 35 dB typical
• Input IP3: 21 dBm typical

Overall, the HMC948LP3ETR from Analog Devices Inc. is a reliable and efficient solution for complex RF mixing requirements, offering a blend of performance, size, and quality that is hard to match.
