Product Overview: LT3090IDD#TRPBF

The LT3090IDD#TRPBF from Analog Devices Inc. is a high-performance, low dropout negative linear regulator designed to provide precision current and voltage control. This component is part of a family of regulators that offer significant improvements over traditional negative LDOs in terms of adjustability, noise, and power dissipation. It is a versatile solution for a wide range of applications, including power supply tracking and negative to positive converter systems.

Key Features

• Adjustable Current and Voltage: The LT3090 can be set to a desired output voltage or current with external resistors, providing excellent flexibility for various design requirements.
• Low Noise: Offering an ultra-low noise output, it is ideal for sensitive applications where a clean power supply is critical.
• Wide Input Voltage Range: Capable of operating with a wide input voltage range, the LT3090 accommodates a variety of input sources.
• Thermal Protection: The device includes internal thermal limiting to protect the regulator and the overall system under high-temperature conditions.
• High Power Dissipation: With its robust design, the LT3090 can dissipate higher levels of power without compromising performance, ensuring reliability even under heavy load conditions.

Applications

• Power supply tracking
• Negative to positive converter systems
• High-precision current sources
• High-quality audio applications
• Instrumentation
• Industrial control systems

Product Specifications

The LT3090IDD#TRPBF is packaged in a compact 8-lead DFN with a temperature range of -40°C to +125°C, suitable for various industrial environments. It supports an output voltage range from -0.2V to -19.5V and a maximum output current of 100mA. The regulator's dropout voltage is typically 300mV at full load, which allows for efficient operation close to the input voltage.

Quality and Reliability

Analog Devices Inc. is renowned for its commitment to quality, and the LT3090IDD#TRPBF is no exception. It is designed to meet the stringent requirements of even the most demanding applications. The product is available in tape and reel packaging, making it suitable for high-volume production environments.

In summary, the LT3090IDD#TRPBF from Analog Devices Inc. offers designers a robust, flexible, and high-performance solution for a variety of negative voltage regulation applications. Its combination of features ensures that it can meet the needs of advanced electronic systems while maintaining high reliability and precision.
