LT6654AHS6-4.096#TRPBF - Precision Voltage Reference

The LT6654AHS6-4.096#TRPBF is a high-precision, low-noise, and low-drift voltage reference from Analog Devices Inc., engineered to provide a stable reference voltage of 4.096 volts. This component is part of the LT6654 series, which is known for its excellent temperature stability and output accuracy, making it an ideal choice for precision applications.

Encased in a compact SOT-23 package, the LT6654AHS6-4.096#TRPBF is designed for space-constrained applications while still offering the robustness and precision required by high-performance systems. It features a typical temperature coefficient of only 10ppm/°C and initial accuracy of 0.05%, ensuring reliable performance across a wide temperature range.

The device operates with a supply voltage range from 2.7V to 5.5V, consuming a low quiescent current, which makes it suitable for battery-powered devices and portable equipment. Additionally, it can source or sink up to 5mA of output current, providing flexibility in a variety of circuit configurations.

Key features of the LT6654AHS6-4.096#TRPBF include:

• Output Voltage: 4.096V
• Initial Accuracy: ±0.05%
• Temperature Coefficient: 10ppm/°C typical
• Supply Voltage Range: 2.7V to 5.5V
• Output Current: ±5mA
• Low Noise: Offering a low noise performance for sensitive applications
• Package: SOT-23
• Operating Temperature Range: -40°C to 125°C

This voltage reference is particularly well-suited for high-resolution analog-to-digital converters (ADCs), digital-to-analog converters (DACs), and precision instrumentation. Its low drift and stable output make it an excellent choice for calibration systems, medical devices, and any other application requiring a precise voltage reference under varying environmental conditions.

The LT6654AHS6-4.096#TRPBF is also available in tape and reel packaging, denoted by the 'TRPBF' suffix, which facilitates automated manufacturing processes, ensuring efficiency and reliability in mass production settings.

With its combination of precision, stability, and low power consumption, the LT6654AHS6-4.096#TRPBF from Analog Devices Inc. represents a state-of-the-art solution for designers who demand the highest levels of accuracy and reliability in their voltage reference applications.
