LTC3775IUD#PBF

Part No LTC3775IUD#PBF
Manufacturer Analog Devices Inc.
Catalog PMIC - Voltage Regulators - DC DC Switching Controllers
Description IC REG CTRLR BUCK 16QFN / Buck Regulator Positive Output Step-Down DC-DC Controller IC 16-QFN (3x3)
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - DC DC Switching Controllers
Mfr Analog Devices Inc.
Series PolyPhase®
Package Tube
Product Status Active
Output Type Transistor Driver
Function Step-Down
Output Configuration Positive
Topology Buck
Number of Outputs 1
Output Phases 1
Voltage - Supply (Vcc/Vdd) 4.5V ~ 38V
Frequency - Switching 250kHz ~ 1MHz
Duty Cycle (Max) 90%
Synchronous Rectifier Yes
Clock Sync Yes
Control Features Current Limit, Enable, Frequency Control, Soft Start
Temperature Range - Operating -40°C ~ 125°C (TJ)
Mounting Type Surface Mount
Package / Case 16-WFQFN Exposed Pad
Supplier Device Package 16-QFN (3x3)
Base Product Number LTC3775
Standard Package 121 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 879703-LTC3775IUD#PBF
Ultra Librarian 3D Model Ultra Librarian LTC3775IUD#PBF CAD Model

Description

Product Overview: LTC3775IUD#PBF

The LTC3775IUD#PBF is a high-performance, dual output synchronous step-down switching regulator controller from Analog Devices Inc., which is renowned for its precision and efficiency. This advanced component is designed to cater to the demanding requirements of modern power supply designs, providing precise control for a dual-phase operation with an input voltage range that makes it suitable for a wide array of applications.

Key Features

  • Wide Input Voltage Range: The LTC3775IUD#PBF operates over a broad input voltage range, accommodating various supply levels and ensuring versatility across different platforms.
  • High Efficiency: With its synchronous step-down architecture, it achieves high conversion efficiency, which is critical for reducing heat and improving system reliability.
  • Dual-Phase Operation: The controller supports dual-phase operation, effectively doubling the output current capability and improving performance by reducing input and output ripple currents.
  • Precision Control: The device offers excellent regulation with features like differential output voltage sensing and programmable soft-start capability, ensuring a smooth power-up sequence.
  • Robust Protection Features: It includes overvoltage, undervoltage, and overcurrent protection, safeguarding the system against a variety of fault conditions.
  • Adjustable Switching Frequency: Users can set the switching frequency from 250kHz to 750kHz or synchronize it to an external clock, providing design flexibility.
  • Compact Package: The LTC3775IUD#PBF comes in a compact 24-lead QFN package, which is ideal for space-constrained applications.

Applications

The LTC3775IUD#PBF is suitable for a range of applications, including but not limited to:

  • Telecommunications Infrastructure
  • Industrial Systems
  • Networking Equipment
  • Automotive Power Systems
  • High-Density Distributed Power Systems

With its robust feature set and adaptability, the LTC3775IUD#PBF from Analog Devices Inc. is a top choice for designers looking to implement a reliable and efficient power management solution in their next project.
