Manufacturer: Analog Devices Inc.

The OP177GSZ-REEL7 is a high-performance operational amplifier (op-amp) from Analog Devices Inc., renowned for its ultra-precision and stability. This op-amp is part of the OP177 series, which is widely recognized for setting industry standards in terms of accuracy and reliability. The OP177GSZ-REEL7 is an ideal choice for applications that demand the highest level of precision and low noise, such as instrumentation, medical equipment, and professional audio electronics.

Key Features:

• Ultra-Precision Performance: Exhibits a very low offset voltage of 25 µV max and offset voltage drift of just 0.3 µV/°C max, ensuring consistent performance over a range of temperatures.
• High Gain Bandwidth: Features a gain bandwidth product of 600 kHz, making it suitable for a variety of applications including filters and integrators.
• Low Noise: With a low noise density of 0.6 µV p-p (0.1 Hz to 10 Hz), this op-amp maintains signal integrity in sensitive applications.
• Wide Supply Range: Can operate from ±2 V to ±18 V dual supply, providing flexibility in a broad range of applications.
• Robust Output Drive Capability: Capable of driving ±10 mA, allowing it to handle a wide array of loads.

Applications:

• High-Precision Instrumentation
• Test and Measurement Systems
• Medical Equipment
• Professional Audio Equipment
• Thermocouple Amplifiers
• Industrial Process Controls

The OP177GSZ-REEL7 comes in a surface-mount, SOP-8 package and is supplied on a 7-inch reel, which is convenient for automated assembly processes. The device is characterized for operation from -55°C to +125°C, covering a wide range of environmental conditions. With its exceptional linearity and very low input bias currents, it is also an excellent choice for high-impedance sensor amplification and precision filters.

As a product of Analog Devices Inc., a leader in the field of high-performance analog technology, the OP177GSZ-REEL7 represents a reliable and cutting-edge solution for critical precision amplification needs.
