3266W-1-503LF Real Image 3266W-1-503LF real image 3266W-1-503LF Real Image1 3266W-1-503LF Real Image2 3266W-1-503LF Real Image3 3266W-1-503LF Real Image4
Same model may have multiple batches, images only for reference.
3266W-1-503LF Real Image 3266W-1-503LF real image 3266W-1-503LF Real Image1 3266W-1-503LF Real Image2 3266W-1-503LF Real Image3 3266W-1-503LF Real Image4
3266W-1-503LF Real Image 3266W-1-503LF real image 3266W-1-503LF Real Image1 3266W-1-503LF Real Image2 3266W-1-503LF Real Image3 3266W-1-503LF Real Image4
Same model may have multiple batches, images only for reference.

3266W-1-503LF

Part No 3266W-1-503LF
Manufacturer Bourns Inc.
Catalog Trimmer Potentiometers
Description TRIMMER 50K OHM 0.25W PC PIN
Datasheet
3266W-1-503LF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Categories Potentiometers, Variable Resistors
Manufacturer Bourns Inc.
Packaging Tube/Rail
Status Active
Resistance (Ohms) 50k
Power (Watts) 0.25W, 1/4W
Tolerance ±10%
Temperature Coefficient ±100ppm/°C
Number of Turns 12
Adjustment Type Top Adjustment
Resistive Material Cermet
Mounting Through Hole
Termination Style PC Pins
Dimension Rectangular - 0.250" x 0.170" Face x 0.270" H (6.35mm x 4.31mm x 6.85mm)
Win Source Part Number 090678-3266W-1-503LF
Family Name 3266
Introduction Date May 18, 2004
ECCN EAR99
Country of Origin Costa Rica
Halogen Free Compliant
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian 3266W-1-503LF CAD Model

Description

Product Overview

The 3266W-1-503LF offers a balance of precision and durability for applications requiring precise resistance control. This model is an integral component in specialized electronic systems.

Features and Benefits

  • 50000-ohm resistance: Ideal for applications needing variable and precise control.
  • Reliable design: Ensures long-term performance and stability.
  • Easy integration: Compatible with various electronic circuits.

Applications

  • Telecommunication devices
  • Medical equipment
  • Automated test equipment
  • Signal processing circuits

The 3266W-1-503LF stands out for its adaptability and precision, serving essential roles in advanced electronic applications.
