Same model may have multiple batches, images only for reference.

SDE0604A-1R2M

Name: SDE0604A-1R2M
Brand: Bourns Inc.
SKU: 1274927
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

Part No	SDE0604A-1R2M
Manufacturer	Bourns Inc.
Catalog	Fixed Inductors
Datasheet	SDE0604A-1R2M Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Mfr	Bourns Inc.
Series	SDE0604A
Package	Tape & Reel
Type	Drum Core, Wirewound
Material - Core	Ferrite
Inductance	1.2 µH
Tolerance	±20%
Current Rating (Amps)	5.3 A
Current - Saturation (Isat)	6A
Shielding	Unshielded
DC Resistance (DCR)	20mOhm Max
Frequency - Self Resonant	155MHz
Ratings	AEC-Q200
Temperature Range - Operating	-40°C ~ 125°C
Inductance Frequency - Test	1 MHz
Mounting	SMD (SMT)
Package / Case	Nonstandard
Dimension	0.228" L x 0.205" W (5.80mm x 5.20mm)
Height - Seated (Max)	0.189" (4.80mm)
Base Product Number	SDE0604A
Other Names	SDE0604A-1R2MCT,SDE0604A-1R2MTR,SDE0604A-1R2MDKR
Standard Package	1,000
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.4000
Win Source Part Number	1274927-SDE0604A-1R2M
Ultra Librarian 3D Model	Ultra Librarian SDE0604A-1R2M CAD Model

Alternative Products

Description

The SDE0604A is a wirewound drum core inductor from Bourns Inc.

Inductance: 1.2 µH
Tolerance: ±20%
Shielding: Unshielded
DC Resistance: 20mOhm max
Current: 5.3 A
Current Saturation: 6A
Core Material: Ferrite
Frequency Self-Resonant: 155MHz
AEC-Q200 Rated: Yes
Temperature Range: -40°C to 125°C
Package: Nonstandard
Package: Tape and Reel
Ideal for: Automotive and Industrial applications
