Same model may have multiple batches, images only for reference.
SDE0604A-330M Real Image
Same model may have multiple batches, images only for reference.

SDE0604A-330M

Part No SDE0604A-330M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SDE0604A-330M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SDE0604A
Package Tape & Reel
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 33 µH
Tolerance ±20%
Current Rating (Amps) 1.55 A
Current - Saturation (Isat) 1.1A
Shielding Unshielded
DC Resistance (DCR) 230mOhm Max
Frequency - Self Resonant 17MHz
Ratings AEC-Q200
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 1 MHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.228" L x 0.205" W (5.80mm x 5.20mm)
Height - Seated (Max) 0.189" (4.80mm)
Base Product Number SDE0604A
Other Names SDE0604A-330MTR,SDE0604A-330MDKR,SDE0604A-330MCT
Standard Package 1,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1274920-SDE0604A-330M
Ultra Librarian 3D Model Ultra Librarian SDE0604A-330M CAD Model

Description

The SDE0604A-330M is a fixed inductor manufactured by Bourns Inc.

  • Core Type: Drum Core, Wirewound
  • Shielding: Unshielded
  • Inductance: 33 µH
  • Tolerance: ±20%
  • DC Resistance: 230mOhm Max
  • Temperature Range: -40°C to 125°C
  • Current Rating: 1.55 A
  • Inductance Frequency: 1 MHz
