SDE0805A-330M Real Image
Same model may have multiple batches, images only for reference.

SDE0805A-330M

Part No SDE0805A-330M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SDE0805A
Package Tape & Reel
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 33 µH
Tolerance ±20%
Current Rating (Amps) 2 A
Current - Saturation (Isat) 1.6A
Shielding Unshielded
DC Resistance (DCR) 130mOhm Max
Frequency - Self Resonant 13.2MHz
Ratings AEC-Q200
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 1 MHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.307" L x 0.276" W (7.80mm x 7.00mm)
Height - Seated (Max) 0.217" (5.50mm)
Base Product Number SDE0805A
Other Names SDE0805A-330MDKR,SDE0805A-330MTR,SDE0805A-330MCT
Standard Package 1,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1274900-SDE0805A-330M
Ultra Librarian 3D Model Ultra Librarian SDE0805A-330M CAD Model

Description

The SDE0805A-330M is a fixed inductor from Bourns Inc.

  • Inductance: 33 µH
  • Current Rating: 2A
  • Core: Ferrite
  • DC Resistance: 130 mOhm Max
  • Tolerance: ±20%
  • Compliance: AEC-Q200
  • Application: Automotive
  • Packaging: Tape and Reel
