Same model may have multiple batches, images only for reference.
SDE1006A-3R3M Real Image
Same model may have multiple batches, images only for reference.

SDE1006A-3R3M

Part No SDE1006A-3R3M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SDE1006A-3R3M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SDE1006A
Package Tape & Reel
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 3.3 µH
Tolerance ±20%
Current Rating (Amps) 5.4 A
Current - Saturation (Isat) 6A
Shielding Unshielded
DC Resistance (DCR) 24mOhm Max
Frequency - Self Resonant 48.8MHz
Ratings AEC-Q200
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 1 MHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.394" L x 0.354" W (10.00mm x 9.00mm)
Height - Seated (Max) 0.228" (5.80mm)
Base Product Number SDE1006A
Other Names SDE1006A-3R3MTR,SDE1006A-3R3MCT,SDE1006A-3R3M,SDE1006A-3R3MDKR
Standard Package 800
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1274877-SDE1006A-3R3M
Ultra Librarian 3D Model Ultra Librarian SDE1006A-3R3M CAD Model

Description

The Bourns Inc. 1274877-SDE1006A-3R3M is a fixed inductor with an unshielded drum core and wirewound type.

  • Inductance: 3.3 µH
  • Tolerance: ±20%
  • Core Material: Ferrite
  • DC Resistance (DCR): 24mOhm Max
  • Self-Resonant Frequency: 48.8MHz
  • Mounting: SMD (SMT)
  • Packaging: Tape & Reel
  • Dimension: 0.394" L x 0.354" W (10.00mm x 9.00mm)
  • Height: 0.228" (5.80mm)
  • Category: Inductors, Coils, Chokes
  • Series: SDE1006A
  • Current Rating: 5.4A
  • REACH: Unaffected
